Informasi Detail

Deskripsi:	Pipa / Tabung Stainless Steel	Kelas:	300 seri, 200 seri, 400 seri
Ketebalan dinding:	0.2-10.0mm	Panjang:	2000mm-8000mm atau sebagai permintaan pelanggan
Lebar:	600mm mnt	Permukaan:	NO1, No.4,2B, BA, 6K, 8K, Garis Rambut dengan PVC
Cahaya Tinggi:	tabung las stainless steel , pipa seamless stainless steel

Deskripsi Produk

Bahan:

300series: 301.302.303.304.304L, 309.309s, 310.310S, 316.316L, 316Ti, 317L, 321.347,

200series: 201.202.202cu, 204;

400 seri : 409.409L, 410.420.430.431.440;

Lainnya: 2205.2507.2906.330.660.630.631,17-4ph, 17-7 ph, S31803904L, dll.

Aplikasi:
lingkungan air laut, petrokimia, pupuk, penyulingan minyak, minyak dan gas alam, cahaya / makanan, bubur kertas dan kertas, industri energi dan perlindungan lingkungan.

Pengepakan:

Dengan tutup plastik untuk melindungi kedua ujungnya

Kantong plastik dibungkus pipa luar

Tas anyaman yang dibungkus pipa luar

Semua produk kami dikemas, disimpan, diangkut sesuai dengan peraturan internasional.
Tabung dibungkus dengan kertas anti karat dan cincin baja untuk mencegah kerusakan. Label identifikasi ditandai sesuai dengan spesifikasi standar atau instruksi pelanggan. Kemasan khusus tersedia sesuai kebutuhan pelanggan.
Plus, kotak kayu lapis tersedia untuk perlindungan khusus. Jenis pengepakan lainnya dapat ditawarkan jika diminta

Tipe	Kelas	Kelas	Komponen kimia%
Tipe	Kelas	Kelas	C	Cr	Ni	M N	P	S	Mo	Si	Cu	N	Lain
Baja tahan karat austenitik	201	1Cr17Mn6Ni5N	≤0,15	16.00-18.00	3.50-5.50	5.50－7.50	≤0.060	≤0.030	-	≤1.00	-	≤0,25	-
	201L	03Cr17Mn6Ni5N	≤0.030	16.00-18.00	3.50-5.50	5.50－7.50	≤0.060	≤0.030		≤1.00		≤0,25
	202	1Cr18Mn8Ni5N	≤0,15	17.00-19.00	4,00-6,00	7.50-10.00	≤0.060	≤0.030		≤1.00	-	≤0,25	-
	204	03Cr16Mn8Ni2N	≤0.030	15.00-17.00	1.50-3.50	7.00-9.00						0,15-0,30
		1Cr18Mn10Ni5Mo3N	≤0.10	17.00-19.00	4,00-6,00	8.50-12.00			2.80-3.50			0,20-0,30
		2Cr13Mn9Ni4	0,15-0,25	12.00-14.00	3.70-5.00	8.00-10.00
		2Cr15Mn15Ni2N	0,15-0,25	14.00-16.00	1.50-3.00	14.00-16.00						0,15-0,30
		1Cr18Mn10Ni5Mo3N	≤0,15	17.00-19.00	4,00-6,00	8.50-12.00	≤0.060	≤0.030	2.8-3.5	≤1.00	-	0,20-0,30	-
	301	1Cr17Ni7	≤0,15	16.00-18.00	6.00-8.00	≤2.00	≤0.065	≤0.030	-	≤1.00	-	-	-
	302	1Cr18Ni9	≤0,15	17.00-19.00	8.00-10.00	≤2.00	≤0.035	≤0.030	-	≤1.00	-	-	-
	303	Y1Cr18Ni9	≤0,15	17.00-19.00	8.00-10.00	≤2.00	≤0.20	≤0.030	1)	≤1.00	-	-	-
	303se	Y1Cr18Ni9Se	≤0,15	17.00-19.00	8.00-10.00	≤2.00	≤0.20	≤0.030	-	≤1.00	-	-	Se≥0.15
	304	0Cr18Ni9	≤0,07	17.00-19.00	8.00-10.00	≤2.00	≤0.035	≤0.030	-	≤1.00	-	-	-
	304L	00Cr19Ni10	≤0.030	18.00-20.00	8.00-10.00	≤2.00	≤0.035	≤0.030	-	≤1.00	-	-	-
	304N1	0Cr19Ni9N	≤0,08	18.00-20.00	7.00-10.50	≤2.00	≤0.035	≤0.030	-	≤1.00	-	0,10-0,25	-
	304N2	0Cr18Ni10NbN	≤0,08	18.00-20.00	7.50-10.50	≤2.00	≤0.035	≤0.030	-	≤1.00	-	0,15-0,30	Nb≤0.15
	304LN	00Cr18Ni10N	≤0.030	17.00-19.00	8.50-11.50	≤2.00	≤0.035	≤0.030	-	≤1.00	-	0,12-0,22	-
	305	1Cr18Ni12	≤0,12	17.00-19.00	10.50-13.00	≤2.00	≤0.035	≤0.030	-	≤1.00	-	-	-
	309S	0Cr23Ni13	≤0,08	22.00-24.00	12.00-15.00	≤2.00	≤0.035	≤0.030	-	≤1.00	-	-	-
	310S	0Cr25Ni20	≤0,08	24.00-26.00	19.00-22.00	≤2.00	≤0.035	≤0.030	-	≤1.00	-	-	-
	316	0Cr17Ni12Mo2	≤0,08	16.00-18.50	10.00-14.00	≤2.00	≤0.035	≤0.030	2.00-3.00	≤1.00	-	-	-
		1Cr18Ni12Mo2Ti6)	≤0,12	16.00-19.00	11.00-14.00	≤2.00	≤0.035	≤0.030	1.80-2.50	≤1.00	-	-	Ti5 (C% -0,02) ~ 0,08
		0Cr18Ni12Mo2Ti	≤0,08	16.00-19.00	11.00-14.00	≤2.00	≤0.035	≤0.030	1.80-2.50	≤1.00	-	-	Ti5 * C% -0,70
	316L	00Cr17Ni14Mo2	≤0.030	16.00-18.00	12.00-15.00	≤2.00	≤0.035	≤0.030	2.00-3.00	≤1.00	-	-	-
	316N	0Cr17Ni12Mo2N	≤0,08	16.00-18.00	10.00-14.00	≤2.00	≤0.035	≤0.030	2.00-3.00	≤1.00	-	0,10-0,22	-
	316N	00Cr17Ni13Mo2N	≤0.030	16.00-18.50	10.50-14.50	≤2.00	≤0.035	≤0.030	2.00-3.00	≤1.00	-	0,12-0,22	-
	316J1	0Cr18Ni12Mo2Cu2	≤0,08	17.00-19.00	10.00-14.50	≤2.00	≤0.035	≤0.030	1.20-2.75	≤1.00	1,00-2,50	-	-
	316J1L	00Cr18Ni14Mo2Cu2	≤0.030	17.00-19.00	12.00-16.00	≤2.00	≤0.035	≤0.030	1.20-2.75	≤1.00	1,00-2,50	-	-
	317	0Cr19Ni13Mo3	≤0,12	18.00-20.00	11.00-15.00	≤2.00	≤0.035	≤0.030	3,00-4,00	≤1.00	-	-	-
	317L	00Cr19Ni13Mo3	≤0,08	18.00-20.00	11.00-15.00	≤2.00	≤0.035	≤0.030	3,00-4,00	≤1.00	-	-	-
		1Cr18Ni12Mo3Ti6	≤0,12	16.00-19.00	11.00-14.00	≤2.00	≤0.035	≤0.030	2.50-3.50	≤1.00	-	-	Ti5 (C% -0,02) ~ 0,08

		0Cr18Ni12Mo3Ti	≤0,08	16.00-19.00	11.00-14.00	≤2.00	≤0.035	≤0.030	2.50-3.50	≤1.00	-	-	Ti5 * C% -0,70
	317J1	0Cr18Ni16Mo5	≤0,040	16.00-19.00	15.00-17.00	≤2.00	≤0.035	≤0.030	4,00-6,00	≤1.00	-	-	-
	321	1Cr18Ni9Ti6	≤0,12	17.00-19.00	8.00-11.00	≤2.00	≤0.035	≤0.030	-	≤1.00	-	-	Ti5 (C% -0,02) ~ 0,08
		0Cr18Ni10Ti	≤0,08	17.00-19.00	9.00-12.00	≤2.00	≤0.035	≤0.030	-	≤1.00	-	-	Ti≥5 * C%
	347	0Cr18Ni11Nb	≤0,08	17.00-19.00	9.00-13.00	≤2.00	≤0.035	≤0.030	-	≤1.00	-	-	Nb≥10 * C%
	XM7	0Cr18Ni9Cu3	≤0,08	17.00-19.00	8.50-10.50	≤2.00	≤0.035	≤0.030	-	≤1.00	3,00-4,00	-	-
	XM15J1	0Cr18Ni13Si4	≤0,08	15.00-20.00	11.50-15.00	≤2.00	≤0.035	≤0.030	-	3.00-5.00	-	-	2)
Austenit Baja Ferit Stainless	329J1	0Cr26Ni5Mo2	≤0,08	23.00-28.00	3.00-6.00	≤1.50	≤0.035	≤0.030	1,00-3,00	≤1.00	-	-	2)
		1Cr18Ni11Si4AlTi	0,10-0,18	17.50-19.50	10 .-- 120 ..	≤0.80	≤0.035	≤0.030	-	3.40-4.00	-	-	Al 0.10-0.30; Ti 0,40-0,70
		00Cr18Ni5MoSi2	≤0.030	18.00-19.50	4,50-5,50	1,00-2,00	≤0.035	≤0.030	2.50-3.00	1.30-2.00	-	-	-
Baja Ferit Stainless	405	0Cr13Al	≤0,08	11.50-14.50	3)	≤1.00	≤0.035	≤0.030	-	≤1.00	-	-	Al 0.10-0.30
	410L	00Cr12	≤0.030	11.00-13.00	3)	≤1.00	≤0.035	≤0.030	-	≤1.00	-	-	-
	430	1Cr17	≤0,12	16.00-18.00	3)	≤1.25	≤0.035	≤0.030	-	≤0,75	-	-	-
	430F	Y1Cr17	≤0,12	16.00-18.00	3)	≤1.00	≤0.035	≥0,15	1)	≤1.00	-	-	-
	434	1Cr17Mo	≤0,12	16.00-18.00	3)	≤1.00	≤0.035	≤0.030	0,75-1,25	≤1.00	-	-	-
	447J1	00Cr30Mo2	≤0.010	28.50-32.00	-	≤0,40	≤0.035	≤0.030	1.50-2.50	≤0,40	-	≤0.015	-
	XM27	00Cr27Mo	≤0.010	25.00-27.50	-	≤0,40	≤0.035	≤0.030	0,75-1,50	≤0,40	-	≤0.015	-
Baja tahan karat martensit	403	1Cr12	≤0,15	11.50-13.00	3)	≤1.00	≤0.035	≤0.030	-	≤0,50	-	-	-
	410	1Cr13	≤0,15	11.50-13.50	3)	≤1.00	≤0.035	≤0.030	-	≤1.00	-	-	-
	405	0Cr13	≤0,08	11.50-13.50	3)	≤1.00	≤0.035	≤0.030	-	≤1.00	-	-	-
	416	Y1Cr13	≤0,15	12.00-14.00	3)	≤1.25	≤0.035	≥0,15	1)	≤1.00	-	-	-
	410J1	1Cr13Mo	≤0.08-0.18	11.50-14.00	3)	≤1.00	≤0.035	≤0.030	0,30-0,60	≤0.60	-	-	-
	420J1	2Cr13	0,16-0,25	12.00-14.00	3)	≤1.00	≤0.035	≤0.030	-	≤1.00	-	-	-
	420J2	3Cr13	0,26-0,35	12.00-14.00	3)	≤1.00	≤0.035	≤0.030	-	≤1.00	-	-	-

	420F	Y3Cr13	0,26-0,40	12.00-14.00	3)	≤1.25	≤0.035	≥0,15	1)	≤1.00	-	-	-
		3Cr13Mo	0,28-0,35	12.00-14.00	3)	≤1.00	≤0.035	≤0.030	0,50-1,00	≤0.80	-	-	-
		4Cr13	0,36-0,45	12.00-14.00	3)	≤0.80	≤0.035	≤0.030	-	≤0.60	-	-	-
	431	1Cr17Ni2	0,11-0,17	16.00-18.00	1.50-2.50	≤0.80	≤0.035	≤0.030	-	≤0.80	-	-	-
	440A	7Cr17	0,60-0,75	16.00-18.00	3)	≤1.00	≤0.035	≤0.030	4)	≤1.00	-	-	-
	440B	8Cr17	0,75-0,95	16.00-18.00	3)	≤1.00	≤0.035	≤0.030	4)	≤1.00	-	-	-
		9Cr18	0,90-1,00	17.00-19.00	3)	≤0.80	≤0.035	≤0.030	4)	≤0.80	-	-	-
	440C	11Cr17	0.95-1.20	16.00-18.00	3)	≤1.00	≤0.035	≤0.030	4)	≤1.00	-	-	-
	440F	Y11Cr17	0.95-1.20	16.00-18.00	3)	≤1.25	≤0.035	≥0,15	4)	≤1.00	-	-	-
		9Cr18Mo	0.95-1.10	16.00-18.00	3)	≤0.80	≤0.035	≤0.030	0,40-0,70	≤0.80	-	-	-
		9Cr18MoV	0,85-0,95	17.00-19.00	3)	≤0.80	≤0.035	≤0.030	1,00-1,30	≤0.80	-	-	V0.07-0.12
Baja Tahan Karat PH	630	0Cr17Ni4Cu4Nb	≤0,07	15.50-17.50	6.50-7.50	≤1.00	≤0.035	≤0.030	-	≤1.00	3.00-5.00	-	Nb 0,15-0,45
	631	0Cr17Ni7Al	≤0,09	16.00-18.00	6.50-7.50	≤1.00	≤0.035	≤0.030	-	≤1.00	≤0,50	-	Al 0.75-1.50
	632	0Cr15Ni7Mo2Al	≤0,09	14.00-16.00	6.50-7.50	≤1.00	≤0.035	≤0.030	2.00-3.00	≤1.00	-	-	Al 0.75-1.50

Tabel perbandingan antara baja tahan karat dalam dan luar negeri dan baja tahan api

	GB	RUSIA	AISI, ASTM	JIS	BS	KERIUHAN	ISO
1	1Cr18Ni9	12KH18H9	302, S30200	SUS302	302S25	X12CrNi88	12
2	0Cr18Ni9	08KH18H10	304, S30400, TP304	SUS304	304S15	X5CrNi89	11
3	00Cr19Ni10	Z2CN18.09	304L, S30403, TP304L	SUS304L	304S12	X2CrNi189	10
4	1Cr18Ni9Ti					X10CrNiTi189
5	0Cr18Ni10Ti	Z6CNT18.10	321, S32100, TP321	SUS321	304S12,321920	X10CrNiTi189	15
6	0Cr17Ni12Mo2	08KH17H13M2T	316, S31600, TP316	SUS316	316S16	XSCrMo1810	20,20
7	0-Cr18Ni12Mo2 Ti	Z6CNDT17.12			320S17	X10CrNIMoTi1810
8	00Cr17Ni14Mo2	03KH17H14M2	316L, S31603, TP316L	SUS316L	316S12	X2Cr	19,19
9	0Cr25Ni20		310S, S31008, TP310S	SUS310S
10	0Cr19Ni13Mo3	08KH17H15M3T	317, S31700, TP317	SUS317	317S16		25
11	00Cr19Ni13Mo3	03KH16H15M3	317L, S31703, TP3178	SUSU317L	317S12	X2CrNiMo1816	24
12	1Cr18Ni12	12KH18H12T	305, S30500	SUSU305	305S19	X5CrNi911	13
13	0Cr18Ni11Nb	08KH18H12B	347, S34700, TP347	SUSU347	347S17	X10CrNiNb189	16
14	1Cr17Ni7	Z12CB17.07	301, S30100	SUSU301	301S21	X12CrNi188	14
15	0Cr23Ni13		309S, S30908	SUS309S
16	0Cr17Ni12Mo2N		316N, S31651	SUS316N
17	00Cr17Ni12Mo2N	Z2CND7.12N		SUS316LN		X2CrNiMoN1812
18	0Cr18Ni12Mo2Cu			SUS316JI
19	00Cr18Ni14Mo2Cu2			SUS316JIL
20	00Cr18Ni14MoCu2	ZCNS18.09A2	304	SUS304N

Label:

Tempat asal:	Cina
Nama merek:	BOZHONG
Sertifikasi:	ISO / TUV / DNV
Nomor model:	300 seri, 200 seri, 400 seri

Kuantitas min Order:	Negotiable
Harga:	negotiable
Kemasan rincian:	No input file specified.
Waktu pengiriman:	3-10 hari
Syarat-syarat pembayaran:	L/C, T/T, Western Union, MoneyGram
Menyediakan kemampuan:	10000 Ton/bulan
